Facing rebar clashes or site placement delays?
Our rebar detailing team delivers constructible drawings and clash-free bar layouts.
Rebar Detailing Services
Precision Rebar Detailing That Turns Concrete Into Structure
At Gsource Technologies, our team of experienced rebar detailers and structural engineers backed by 16+ years of AEC project delivery and ISO-certified workflows ensures reinforcement bars are placed precisely where structural design demands them across foundations, columns, beams, slabs, and walls. These details integrate seamlessly into BIM solutions, shop drawings, prefab details, precast detailing, reinforced concrete detailing & more. We assist with the full range of detailing requirements, bar sizes and grades, locations and spacing, bend details, lap splices, development lengths, concrete cover requirements, stirrups, and ties - producing 2D AutoCAD placement drawings and 3D models in Tekla Structures and Revit. Every deliverable is reviewed against ACI 318, ASTM A615/A706, and CRSI standards by our QA team before delivery. We use RebarCAD, AutoCAD, Revit, RGS Rebar, Tekla Structures, and MultiSUITE to produce fabrication-ready drawings your fabricators can act on and your engineer of record can approve without revision cycles.
Certification:
9001:2015
27001-2022
19650-1:2018
14001:2015
45001:2018
9001:2015 27001-2022 19650-1:2018 14001:2015 45001:2018
What Our Clients Achieve
Up to 30% faster detailing turnaround for large-scale concrete and infrastructure projects
Highly accurate bar bending schedules and placement drawings, minimizing site errors
2D & 3D rebar models compatible with BIM, precast, and fabrication workflows
Full compliance with ACI 318, ASTM A615/A706, CRSI, BS 8666, and regional project codes
Up to 40% cost savings through optimized bar layouts and reduced material wastage
Associated With
Show More
Our Core Services
Bar Sizes and Grades
We specify bar diameters from #3 to #18 and grades per ACI 318, ASTM A615, A706, and CRSI requirements, aligned with your structural engineer's design intent.
Bar Locations and Spacing
Placement drawings include clear cover dimensions, development lengths, and lap splice zones, giving field crews unambiguous installation instructions.
Bend Details
Each bend schedule includes shape codes, bend angles, hook dimensions, and radii per CRSI and ASTM standards, ready for direct input to fabrication equipment.
Stirrups and Ties
We detail closed and open stirrups, seismic hoops, and spiral ties for columns, beams, and shear walls, including spacing transitions near support zones.
Rebar Drawings and Scheduling
Bar bending schedules list bar mark, shape code, diameter, cutting length, and quantity formatted for direct fabricator use with no manual interpretation required.
2D and 3D Modeling
3D models in Tekla Structures or Revit allow multi-trade clash detection before drawings are issued catching conflicts with MEP, structural steel, and precast elements early.
As-built Drawings
Produced post-installation to reflect final field conditions, as-built rebar documentation is essential for structural renovations, retrofits, and regulatory sign-offs.
Roof Truss and Joint Details
Connection and joint details cover bearing zones, embedment plates, and reinforcement continuity at transfer levels, high-seismic joints, and precast interfaces.
Total Rebar Estimation
Full quantity take-offs covering bar weight by element type, accessories, and erection inputs formatted for estimating teams and procurement workflows.
Grade Beam Detailing
Grade beam drawings include top and bottom mat reinforcement, stirrup spacing, tie conditions, corner details, and construction joint locations.
Foundation Details
Foundation rebar detailing covers spread footings, pile caps, raft slabs, and mat foundations, with dowel schedules and column base plate interface details.
Rebar Shop Drawings
Delivered in DWG, PDF, or IFC format shop drawings include bar marks, bending shapes, placement notes, and tie wire details, reviewed against ACI 318, ASTM, and CRSI before issue.
Strategic Engagement Models
Get tailored solutions to fit your project’s scale and complexity
Project-Based
Clearly defined deliverables & fixed-scope milestones.
Retainer / FTE
Ongoing technical support & on-demand expertise.
Dedicated Team (POD)
High-volume multi-disciplinary, & long-term integration.
Hybrid Model
Adaptive workflows & complex, evolving project requirements.
What Do Our Clients Say?
Why Choose Gsource for Rebar Detailing
Proven Performance on Complex Concrete Programs
Over 16 years of experience delivering rebar detailing for high-rise buildings, infrastructure, industrial facilities, healthcare campuses, and large-scale developments worldwide.
Fabrication-Ready Quality with Secure Processes
ISO 9001 and ISO 27001 certified workflows ensure accurate, fabrication-ready rebar outputs with strict revision control and secure handling of sensitive project data.
Scalable Production for Fast-Track Concrete Schedules
Global delivery teams capable of producing 300+ rebar shop drawings and bar bending schedules daily, supporting high-volume concrete packages and accelerated pour cycles.
Seamless Alignment with Your Rebar Detailing Standards
We integrate into your detailing standards, bar mark conventions, approval workflows, BEP requirements, and delivery milestones as an extension of your project team.
Advanced Rebar Detailing Tool Expertise
Expertise across Revit, Tekla Structures, AutoCAD, RGS Rebar, RebarCAD, Navisworks, BIM 360, ACC, and fabrication-ready BBS outputs.
Measurable Impact on Fabrication and Site Execution
Clients report fewer RFIs, reduced bar wastage, smoother approvals, and faster placement cycles, validated through repeat engagements and project case studies.
Our Workflow
Book a free consultation
Get expert support to streamline your next project.
Free Initial Consultation - No Commitment Required
Secure and Confidential Project Information
16+ Years of AEC Expertise
450+ Drawing Deliverables Daily
Industry Standards Compliance Guaranteed
FAQs
You can engage Gsource by initially scheduling a call with our team or by directly sharing your structural drawings, specifications, reinforcement standards, and project schedules. Our team will then review the scope and propose a rebar detailing plan that fits perfectly with your codes, pour sequencing, and site workflows.
Gsource delivers end-to-end rebar detailing services. These include 3D modeling, shop drawings, bar bending schedules (BBS), quantity take-offs, placement drawings, and as-built documentation.
It is simple- you can submit your project details through our website or contact our team directly. We will review the scope and typically share a detailed, transparent estimate within one working day.
Yes. We specialize in rebar detailing for high-rise buildings, infrastructure projects, industrial facilities, healthcare campuses, and large commercial developments with complex reinforcement requirements.
Yes. All Gsource rebar detailing services are driven by accurate 3D models to ensure constructability, coordination, and clash-free reinforcement layouts before site execution.
Absolutely. We adapt to your reinforcement standards, bar mark conventions, BBS formats, file naming structures, and internal QA workflows from project kickoff.
Before drawings are sent for approval and construction, our team establishes multi-trade coordination. We coordinate rebar models with structural, architectural, and MEP teams and address any constructability issues that might arise.
For ensuring quality control and data security, our workflows are aligned with ISO 9001 and ISO 27001. We follow multi-level QA/QC checks, secure data handling, NDAs, and controlled access for sensitive project information.
